ECOFLOW 220W BIFACIAL SOLAR PANEL

Two in one EcoFlow’s 220W Bifacial Portable Solar Panel is two in one. With a 220W primary side and a 155W side on the back for ambient light, you can capture up to 25% more solar energy and charge your portable power station even faster. Try a mirrored surface and you can get up to 80% more energy.

Tempered glass. Built to last The thin, one-piece tempered glass design makes it five times tougher than comparable panels, it can withstand heat up to 148°C too. Safe to say it can withstand the elements.

Compact. Portable It’s a portable solar panel designed from the ground up to be compact. 10% smaller than comparable 220W panels, it saves space with thinner tempered glass, and less surface area required for the same input.

More than a carry case It comes with its own carry case so you can take it anywhere. Once you arrive at your destination, simply unfold it and use it as a kickstand to get your sun exposure just right.

Waterproof We’ve raised the bar with this panel. It's completely water and dust-tight. Rain, wind or shine, your panel is safe with an IP68 waterproof rating.

EF 220W Portable Solar Panel General info:

• Unfolded Dimensions: 183 x 82 x 2.5cm
• Folded Dimensions: 50 x 82 x 3.2cm
• Weight: 14kg with carrying case (9.5kg solar panel only)
• Material: tempered glass
• Rated Power: 220W Front Side | 155W Rear Side (+/- 5%)
• Bifaciality Coefficients: 70%±10%
• VOC:  Voltage open circuit 21,8V
• Isc: 13A at the front side | 8.8A at the rear side
• Vmp: Voltage maximum power 18.4V
• Imp: 12A at the front side | 8.4A at the rear side
• Solar cells: Monocrystalline silicon (22%-23% Efficiency)
• Output type: MC4 Solar Port
• Waterproof: IP67
• Chainable: Yes (follow the instructions in your manual)

WHAT'S IN THE BOX?

• 1 x EF 220W Bifacial Solar Panel with MC4 wiring harness
• 1 x Carrying Case (Kickstand)
• 1 x User Manual

Warranty: 2 Year Manufacturers Warranty accessible in New Zealand

User Manual:

Download 220W Bifacial Solar Panel User Manual
